Products Introduction
The glass prefilled syringe is a medical device that has changed the traditional way of injection, making the injection process safer, more convenient and efficient. The glass prefilled syringe consists of needle, syringe and medicine, in which the medicine has been prefilled in the syringe and can be used directly without the need to extract it from the bottle. The design of this syringe can reduce the risk of pollution and cross-infection, and also avoid errors caused by improper operation. The glass prefilled syringes are widely used in medical fields including vaccine inoculation, cancer treatment, growth hormone injection, etc. With the continuous development of medical technology, the application prospects of glass prefilled syringes will become more extensive.
Specifications and dimensions
Specification | d1 | d2 | d3 | d4 | h1 | h2 |
1ml slight | 8.1±0.1 | 6.3±0.1 | 13.8±0.4 | 11.0±0.4 | 55.0±0.5 | 1.8±0.2 |
1ml standard | 10.8±0.1 | 8.6±0.1 | 17.8±0.5 | 14.7±0.5 | 37.5±0.5 | 1.8±0.2 |
2.25ml standard | 10.8±0.1 | 8.6±0.1 | 17.8±0.5 | 14.7±0.5 | 55.5±0.5 | 1.8±0.2 |
3ml standard | 10.8±0.1 | 8.6±0.1 | 17.8±0.5 | 14.7±0.5 | 73.0±0.5 | 1.8±0.2 |
5ml standard | 14.4±0.1 | 11.8±0.1 | 23.0±1.0 | 19.5±0.5 | 69.0±0.5 | 2.4±0.2 |
10ml standard | 17.0±0.2 | 14.2±0.2 | 27.0±1.0 | 21.5±0.5 | 87.2±0.5 | 2.5±0.6 |
